100% Full Pine LVL Beam for Structural or House Frame Use AS/NZS4357.0 with Benchark Certification

FLEX Frame and beams LVL Boards AS/NZS4357.0
F/B: Sanding well H2.0 H1.2 Treated/Boron-based treaments
Material: Full Larch pine Glue: Dynea phenolic resin, A-BONDS, E0
Thickness: 35mm,45mm, 65mm,77mm
Width: 90mm,140mm,190mm,240mm,290mm,300mm,360mm etc.
Length: 1.2mm,2.4mm,3.6m,4.2m,4.8m,5.4m,6m
Treated: by H2.0,H1.2
Certification: by Bencharmk
Availability:
Quantity:
  • 90*45*3900MM

  • HC

  • 4412390090

Product Description

structural laminated veneer lumber (LVL) which has been manufactured in accordance with AS/NZS 4357
with properties determined in accordance with AS/NZS 4063.2 and therefore complies with the requirements
for structural design in accordance with AS1720.1

structural LVL is manufactured using an 'A' Bond with less than 0.5mg/l Formaldehyde (equivalent to E0)
emissions from the final product.

a full range of LVL sizes from 95 x 45mm right up to 220 x 75mm.
Meets AS/NZS 4357 (Structural LVL)

Produced in industry-standard sizes

Painted 'safety yellow/ red/ blue' for easy identification

Can be used as for concrete formwork support structures such as joists, bearers, walers and soldiers

Also suitable for edge boards in concrete formwork framing projects and boxing for residential slabs.
